Finish:Mirror or Matt Polish; Ra<0.4um
1. Material:Stainless steel, austenitic stainless steel 304, 316L etc, with insulating material or not
2. Tank shell thickness:3mm at least (according to the design or your required)
3. Design work pressure (MPa):0.2MPa (According to the China national standard, breakthroughs in the foregoing measurements are allowed in special cases)
4. General accessories(If required):Manhole, CIP, respirator, sight glass, mixing(Top side or bottom)
Certification: CE ISO9001:2000.
| Main Parameters | ||||||
| Model | Equipment volume（BBL) | Diameter of Tank（mm) | Cylindrical Height(mm) | Outine dimension（mm) | ||
| Length | Width | Height | ||||
| RLG-2BBL | 2BBL | φ800 | 600 | 800 | 800 | 1400 |
| RLG-7BBL | 7BBL | φ1000 | 750 | 1000 | 1000 | 1650 |
| RLG-10BBL | 10BBL | φ1100 | 1000 | 1100 | 1100 | 1900 |
| RLG-15BBL | 15BBL | φ1500 | 1000 | 1500 | 1500 | 2150 |
| RLG-25BBL | 25BBL | φ1600 | 1220 | 1600 | 1600 | 2400 |
| RLG-30BBL | 30BBL | φ1700 | 1500 | 1700 | 1700 | 2750 |
| RLG-40BBL | 40BBL | φ1900 | 1500 | 1900 | 1900 | 2850 |
| RLG-50BBL | 50BBL | φ2100 | 1500 | 2100 | 2100 | 3000 |
|
we can design drawing according to your requirement. |
||||||
