Stainless steel jacket kettle is design to cooking both low viscosity and high viscosity processing material in food, beverage industries. Jacket kettle is design to meet high grade food standard. All contact parts are made of 304 or 316 Stainless. No dead conner, Easy cleaning. Inner surface finish adopt Mirror polish Ra<0.4um. It is a more convenience and cheaper solution than jacketed tanks, Volume for jacket kettle from 100L to 500L. For high viscosity processing material, the agitator could be customized with PTFE scraper.
1. Material:Stainless steel, austenitic stainless steel 304, 316L etc, with insulating material or not
2. Tank shell thickness:3mm at least (according to the design or your required)
3. Design work pressure (MPa):-0.1~~1.6MPa (According to the China national standard, breakthroughs in the foregoing measurements are allowed in special cases)
4. Design work temperature:-4~~ 150C
5. General accessories(If required):Manhole, CIP, respirator, sight glass, mixing(Top side or bottom)
Bottom magnetic agitator with propeller impeller, speed from 50-400rpm or 50-800rpm. this kind of agitator is mixing thin viscosity , such as eyedrop, injection, CIP liquid, water, etc.
Material:Stainless steel, austenitic stainless steel 304, 316L etc, with insulating material or not.
Material:Stainless steel, austenitic stainless steel 304, 316L etc, with insulating material or not.
Material:Stainless steel, austenitic stainless steel 304, 316L etc, with insulating material or not.
Plate Sterilizer complete sets of equipment is designed for milk, dairy products, fruit juices, drinks, beer and other liquid materials designed for sterilization equipment. Using manual, semi-automatic, fully automatic three control systems, control components are brand-name products, including industrial PLC programmable controller and screen, the steam valve, control valve, diverter valve, pump and heat pump materials. Other valves and pipe fittings and other fluid accessories selected high quality standards for all products. According to technical requirements of different users, the combination of different process design.
Tubular Sterilizer for milk sterilization, juice sterilization, beverages sterilization and other liquid food sterilization.Capacity various from 0.5T-20T.
Flash Pasteurizer for milk sterilization, juice sterilization, beverages sterilization and other liquid food sterilization.Capacity various from 0.5T-20T.
1.the filter cylinder is 1core,3core,5core,7core,9core,11core,13core,15core
2.the length of folding filter core is 10,20,30,40
3.the material of the filter core is PTF,Pplysulfone,nylon,pp,acetyl cellulose
4.the diameter of the filter hole is 0.1μm,0.22μm,0.45μm,1μm,3μm,5μm,10μm,30μm,60μm,and it is selective as hydrophilic (suitable for gas) and hydrophilic (suitable for liquid) according to your requirement.
1.the filter cylinder is 1core,3core,5core,7core,9core,11core,13core,15core
2.the length of folding filter core is 10,20,30,40
3.the material of the filter core is PTF,Pplysulfone,nylon,pp,acetyl cellulose
4.the diameter of the filter hole is 0.1μm,0.22μm,0.45μm,1μm,3μm,5μm,10μm,30μm,60μm,and it is selective as hydrophilic (suitable for gas) and hydrophilic (suitable for liquid) according to your requirement.
1.Material:SS304,SS316L
2.Design vessel pressure :0.6-1.0Mpa
3.Operate temperature:-20-140°C
4.Filtering accuracy: 0.1-50um
5.Filter Bag type:1#Bay,2#Bag,3#Bag,4#Bag
